Installation boxes · for installers

Shower installation box with a built-in concealed valve body.

A shower installation box brings hot and cold water into the wall ready-piped, on request with the concealed valve body in place. SANOOX makes it in 156 versions for masonry and drywall, for 31 pipe systems in 16 or 20 mm.

ConfigureExplore models
SANOOX shower installation box M05.1120 for masonry, pink XPS body with two wall-plate elbows and pipes pointing down

Installation boxes for the shower, masonry and drywall

156 boxes · dimensions in mm, drawings schematic
Shower · from the field

Questions about the shower installation box.

Short answers to what matters before you order. If anything is still unclear, the box assistant or our office in Pöllau can help.

ConfigureContact
What is a shower installation box?

A factory-piped XPS insulating body that positions hot and cold water for the shower fitting in the wall. At SANOOX it comes with a built-in concealed valve body or with wall-plate elbows for a surface-mounted fitting, in 156 versions for masonry and drywall.

Which concealed valve bodies are built in?

Hansgrohe iBox 2.0 0150, Hansgrohe iBox 0180, Grohe Smartbox 35604, Hansa Blue Box 8000 and Kludi Flexx Boxx 88011. The concealed valve body is named in the model text of each box.

How is the overhead shower connected?

In three ways: via boxes with a connection pipe for the overhead shower, via tall boxes with a connection for the overhead and hand shower, or via the single outlet for the overhead shower, a dedicated small box of 140 × 290 mm in masonry and 350 × 290 mm in drywall.

Does the box have a waste for the shower?

No. The shower boxes carry the water to the fitting; the floor drain or shower channel is planned separately.

Is a splash-water sleeve available?

Yes, as option 00195 for all shower boxes. Also as options: insulation to the pipe end (00198) and a construction plug in brass (00197) or plastic (00196).

What pipe size does the Shower installation box use?

16 or 20 mm, depending on the variant; with Roth pipe 17 instead of 16 mm. PP pipe (Aquatec, Harreither and Kelit Kelen) is available in 20 or 25 mm. Not every box shape comes in every size; the dimension table shows what applies to each box.

How is the article number structured?

It is built from Box, Pipe system and Dimension. Example M05.1120.22.16: Box M05.1120 (Dusche kurz, ohne Unterputzkörper, Massivbau), Pipe system 22 (Viega Raxofix), 16 mm. The configurator shows the finished number.

Where do I order the Shower installation box?

Through your plumbing and heating merchant, using the full article number; SANOOX does not supply end customers. Build project lists in the configurator and send them to SANOOX as an enquiry.

Dimensions of the shower installation boxes

BoxVersionW × H × D (mm)Pipe (mm)
M05.0360MasonryShower, long, pipes exit at the bottom, long pipes240 × 1250 × 7016/20 · 20/25
M05.1120MasonryShower, short, pipes exit at the bottom, long pipes240 × 200 × 7016/20 · 20/25
M05.1130MasonryShower, short, pipes exit at the bottom/top, short pipes240 × 200 × 7016/20 · 20/25
M05.0352MasonryShower, long, Hansgrohe iBox 2.0 0150, concealed body, incl. hand shower connection, right, pipes exit at the bottom, long pipes450 × 1250 × 7016/20 · 20/25
M05.0372MasonryShower, long, Hansgrohe iBox 0180, concealed body, incl. hand shower connection, right, pipes exit at the bottom, long pipes450 × 1250 × 7016/20 · 20/25
M05.0382MasonryShower, long, Grohe Smartbox 35604, concealed body, incl. hand shower connection, right, pipes exit at the bottom, long pipes450 × 1250 × 7016/20 · 20/25
M05.0392MasonryShower, long, Hansa Blue Box 8000, concealed body, incl. hand shower connection, right, pipes exit at the bottom, long pipes450 × 1250 × 7016/20 · 20/25
M05.0402MasonryShower, long, Kludi Flexx Boxx 88011, concealed body, incl. hand shower connection, right, pipes exit at the bottom, long pipes450 × 1250 × 7016/20 · 20/25
M05.0354MasonryShower, long, Hansgrohe iBox 2.0 0150, concealed body, incl. hand shower connection, left, pipes exit at the bottom, long pipes450 × 1250 × 7016/20 · 20/25
M05.0374MasonryShower, long, Hansgrohe iBox 0180, concealed body, incl. hand shower connection, left, pipes exit at the bottom, long pipes450 × 1250 × 7016/20 · 20/25
M05.0384MasonryShower, long, Grohe Smartbox 35604, concealed body, incl. hand shower connection, left, pipes exit at the bottom, long pipes450 × 1250 × 7016/20 · 20/25
M05.0394MasonryShower, long, Hansa Blue Box 8000, concealed body, incl. hand shower connection, left, pipes exit at the bottom, long pipes450 × 1250 × 7016/20 · 20/25
M05.0404MasonryShower, long, Kludi Flexx Boxx 88011, concealed body, incl. hand shower connection, left, pipes exit at the bottom, long pipes450 × 1250 × 7016/20 · 20/25
M05.0350MasonryShower, long, Hansgrohe iBox 2.0 0150, concealed body, incl. hand shower connection, pipes exit at the bottom, long pipes300 × 1250 × 7016/20 · 20/25
M05.0370MasonryShower, long, Hansgrohe iBox 0180, concealed body, incl. hand shower connection, pipes exit at the bottom, long pipes300 × 1250 × 7016/20 · 20/25
M05.0380MasonryShower, long, Grohe Smartbox 35604, concealed body, incl. hand shower connection, pipes exit at the bottom, long pipes300 × 1250 × 7016/20 · 20/25
M05.0390MasonryShower, long, Hansa Blue Box 8000, concealed body, incl. hand shower connection, pipes exit at the bottom, long pipes300 × 1250 × 7016/20 · 20/25
M05.0400MasonryShower, long, Kludi Flexx Boxx 88011, concealed body, incl. hand shower connection, pipes exit at the bottom, long pipes300 × 1250 × 7016/20 · 20/25
M05.1110MasonryShower, short, Hansgrohe iBox 2.0 0150, concealed body incl. hand shower connection, pipes exit at the bottom, long pipes300 × 400 × 7016/20 · 20/25
M05.1140MasonryShower, short, Hansgrohe iBox 0180, concealed body incl. hand shower connection, pipes exit at the bottom, long pipes300 × 400 × 7016/20 · 20/25
M05.1150MasonryShower, short, Grohe Smartbox 35604, concealed body incl. hand shower connection, pipes exit at the bottom, long pipes300 × 400 × 7016/20 · 20/25
M05.1160MasonryShower, short, Hansa Blue Box 8000, concealed body incl. hand shower connection, pipes exit at the bottom, long pipes300 × 400 × 7016/20 · 20/25
M05.1170MasonryShower, short, Kludi Flexx Boxx 88011, concealed body incl. hand shower connection, pipes exit at the bottom, long pipes300 × 400 × 7016/20 · 20/25
M05.1112MasonryShower, short, Hansgrohe iBox 2.0 0150, concealed body incl. hand shower connection, right, pipes exit at the bottom, long pipes450 × 400 × 7016/20 · 20/25
M05.1142MasonryShower, short, Hansgrohe iBox 0180, concealed body incl. hand shower connection, right, pipes exit at the bottom, long pipes450 × 400 × 7016/20 · 20/25
M05.1152MasonryShower, short, Grohe Smartbox 35604, concealed body incl. hand shower connection, right, pipes exit at the bottom, long pipes450 × 400 × 7016/20 · 20/25
M05.1162MasonryShower, short, Hansa Blue Box 8000, concealed body incl. hand shower connection, right, pipes exit at the bottom, long pipes450 × 400 × 7016/20 · 20/25
M05.1172MasonryShower, short, Kludi Flexx Boxx 88011, concealed body incl. hand shower connection, right, pipes exit at the bottom, long pipes450 × 400 × 7016/20 · 20/25
M05.1114MasonryShower, short, Hansgrohe iBox 2.0 0150, concealed body incl. hand shower connection, left, pipes exit at the bottom, long pipes450 × 400 × 7016/20 · 20/25
M05.1144MasonryShower, short, Hansgrohe iBox 0180, concealed body incl. hand shower connection, left, pipes exit at the bottom, long pipes450 × 400 × 7016/20 · 20/25
M05.1154MasonryShower, short, Grohe Smartbox 35604, concealed body incl. hand shower connection, left, pipes exit at the bottom, long pipes450 × 400 × 7016/20 · 20/25
M05.1164MasonryShower, short, Hansa Blue Box 8000, concealed body incl. hand shower connection, left, pipes exit at the bottom, long pipes450 × 400 × 7016/20 · 20/25
M05.1174MasonryShower, short, Kludi Flexx Boxx 88011, concealed body incl. hand shower connection, left, pipes exit at the bottom, long pipes450 × 400 × 7016/20 · 20/25
M05.0386MasonryShower, long, Hansgrohe iBox 2.0 0150, concealed body incl. overhead shower pipe and hand shower connection, pipes exit at the bottom, long pipes300 × 1250 × 7020/25
M05.0410MasonryShower, long, Hansgrohe iBox 0180, concealed body incl. overhead shower pipe and hand shower connection, pipes exit at the bottom, long pipes300 × 1250 × 7020/25
M05.0420MasonryShower, long, Grohe Smartbox 35604, concealed body incl. overhead shower pipe and hand shower connection, pipes exit at the bottom, long pipes300 × 1250 × 7020/25
M05.0430MasonryShower, long, Hansa Blue Box 8000, concealed body incl. overhead shower pipe and hand shower connection, pipes exit at the bottom, long pipes300 × 1250 × 7020/25
M05.0440MasonryShower, long, Kludi Flexx Boxx 88011, concealed body incl. overhead shower pipe and hand shower connection, pipes exit at the bottom, long pipes300 × 1250 × 7020/25
M05.0387MasonryShower, long, Hansgrohe iBox 2.0 0150, concealed body incl. overhead shower pipe and hand shower connection, right, pipes exit at the bottom, long pipes450 × 1250 × 7020/25
M05.0411MasonryShower, long, Hansgrohe iBox 0180, concealed body incl. overhead shower pipe and hand shower connection, right, pipes exit at the bottom, long pipes450 × 1250 × 7020/25
M05.0421MasonryShower, long, Grohe Smartbox 35604, concealed body incl. overhead shower pipe and hand shower connection, right, pipes exit at the bottom, long pipes450 × 1250 × 7020/25
M05.0431MasonryShower, long, Hansa Blue Box 8000, concealed body incl. overhead shower pipe and hand shower connection, right, pipes exit at the bottom, long pipes450 × 1250 × 7020/25
M05.0441MasonryShower, long, Kludi Flexx Boxx 88011, concealed body incl. overhead shower pipe and hand shower connection, right, pipes exit at the bottom, long pipes450 × 1250 × 7020/25
M05.0388MasonryShower, long, Hansgrohe iBox 2.0 0150, concealed body incl. overhead shower pipe and hand shower connection, left, pipes exit at the bottom, long pipes450 × 1250 × 7020/25
M05.0412MasonryShower, long, Hansgrohe iBox 0180, concealed body incl. overhead shower pipe and hand shower connection, left, pipes exit at the bottom, long pipes450 × 1250 × 7020/25
M05.0422MasonryShower, long, Grohe Smartbox 35604, concealed body incl. overhead shower pipe and hand shower connection, left, pipes exit at the bottom, long pipes450 × 1250 × 7020/25
M05.0432MasonryShower, long, Hansa Blue Box 8000, concealed body incl. overhead shower pipe and hand shower connection, left, pipes exit at the bottom, long pipes450 × 1250 × 7020/25
M05.0442MasonryShower, long, Kludi Flexx Boxx 88011, concealed body incl. overhead shower pipe and hand shower connection, left, pipes exit at the bottom, long pipes450 × 1250 × 7020/25
M05.1166MasonryShower, short, Hansgrohe iBox 2.0 0150, concealed body incl. overhead shower pipe and hand shower connection, pipes exit at the bottom, long pipes300 × 400 × 7020/25
M05.1180MasonryShower, short, Hansgrohe iBox 0180, concealed body incl. overhead shower pipe and hand shower connection, pipes exit at the bottom, long pipes300 × 400 × 7020/25
M05.1190MasonryShower, short, Grohe Smartbox 35604, concealed body incl. overhead shower pipe and hand shower connection, pipes exit at the bottom, long pipes300 × 400 × 7020/25
M05.1200MasonryShower, short, Hansa Blue Box 8000, concealed body incl. overhead shower pipe and hand shower connection, pipes exit at the bottom, long pipes300 × 400 × 7020/25
M05.1210MasonryShower, short, Kludi Flexx Boxx 88011, concealed body incl. overhead shower pipe and hand shower connection, pipes exit at the bottom, long pipes300 × 400 × 7020/25
M05.1167MasonryShower, short, Hansgrohe iBox 2.0 0150, concealed body incl. overhead shower pipe and hand shower connection, right, pipes exit at the bottom, long pipes450 × 400 × 7020/25
M05.1181MasonryShower, short, Hansgrohe iBox 0180, concealed body incl. overhead shower pipe and hand shower connection, right, pipes exit at the bottom, long pipes450 × 400 × 7020/25
M05.1191MasonryShower, short, Grohe Smartbox 35604, concealed body incl. overhead shower pipe and hand shower connection, right, pipes exit at the bottom, long pipes450 × 400 × 7020/25
M05.1201MasonryShower, short, Hansa Blue Box 8000, concealed body incl. overhead shower pipe and hand shower connection, right, pipes exit at the bottom, long pipes450 × 400 × 7020/25
M05.1211MasonryShower, short, Kludi Flexx Boxx 88011, concealed body incl. overhead shower pipe and hand shower connection, right, pipes exit at the bottom, long pipes450 × 400 × 7020/25
M05.1168MasonryShower, short, Hansgrohe iBox 2.0 0150, concealed body incl. overhead shower pipe and hand shower connection, left, pipes exit at the bottom, long pipes450 × 400 × 7020/25
M05.1182MasonryShower, short, Hansgrohe iBox 0180, concealed body incl. overhead shower pipe and hand shower connection, left, pipes exit at the bottom, long pipes450 × 400 × 7020/25
M05.1192MasonryShower, short, Grohe Smartbox 35604, concealed body incl. overhead shower pipe and hand shower connection, left, pipes exit at the bottom, long pipes450 × 400 × 7020/25
M05.1202MasonryShower, short, Hansa Blue Box 8000, concealed body incl. overhead shower pipe and hand shower connection, left, pipes exit at the bottom, long pipes450 × 400 × 7020/25
M05.1212MasonryShower, short, Kludi Flexx Boxx 88011, concealed body incl. overhead shower pipe and hand shower connection, left, pipes exit at the bottom, long pipes450 × 400 × 7020/25
M05.0425MasonryShower, long, Hansgrohe iBox 2.0 0150, concealed body incl. overhead and hand shower connections, pipes exit at the bottom, long pipes300 × 2290 × 7020/25
M05.0450MasonryShower, long, Hansgrohe iBox 0180, concealed body incl. overhead and hand shower connections, pipes exit at the bottom, long pipes300 × 2290 × 7020/25
M05.0460MasonryShower, long, Grohe Smartbox 35604, concealed body incl. overhead and hand shower connections, pipes exit at the bottom, long pipes300 × 2290 × 7020/25
M05.0470MasonryShower, long, Hansa Blue Box 8000, concealed body incl. overhead and hand shower connections, pipes exit at the bottom, long pipes300 × 2290 × 7020/25
M05.0480MasonryShower, long, Kludi Flexx Boxx 88011, concealed body incl. overhead and hand shower connections, pipes exit at the bottom, long pipes300 × 2290 × 7020/25
M05.0426MasonryShower, long, Hansgrohe iBox 2.0 0150, concealed body incl. overhead and hand shower connections, right, pipes exit at the bottom, long pipes300 × 2290 × 7020/25
M05.0451MasonryShower, long, Hansgrohe iBox 0180, concealed body incl. overhead and hand shower connections, right, pipes exit at the bottom, long pipes300 × 2290 × 7020/25
M05.0461MasonryShower, long, Grohe Smartbox 35604, concealed body incl. overhead and hand shower connections, right, pipes exit at the bottom, long pipes300 × 2290 × 7020/25
M05.0471MasonryShower, long, Hansa Blue Box 8000, concealed body incl. overhead and hand shower connections, right, pipes exit at the bottom, long pipes300 × 2290 × 7020/25
M05.0481MasonryShower, long, Kludi Flexx Boxx 88011, concealed body incl. overhead and hand shower connections, right, pipes exit at the bottom, long pipes300 × 2290 × 7020/25
M05.0427MasonryShower, long, Hansgrohe iBox 2.0 0150, concealed body incl. overhead and hand shower connections, left, pipes exit at the bottom, long pipes300 × 2290 × 7020/25
M05.0452MasonryShower, long, Hansgrohe iBox 0180, concealed body incl. overhead and hand shower connections, left, pipes exit at the bottom, long pipes300 × 2290 × 7020/25
M05.0462MasonryShower, long, Grohe Smartbox 35604, concealed body incl. overhead and hand shower connections, left, pipes exit at the bottom, long pipes300 × 2290 × 7020/25
M05.0472MasonryShower, long, Hansa Blue Box 8000, concealed body incl. overhead and hand shower connections, left, pipes exit at the bottom, long pipes300 × 2290 × 7020/25
M05.0482MasonryShower, long, Kludi Flexx Boxx 88011, concealed body incl. overhead and hand shower connections, left, pipes exit at the bottom, long pipes300 × 2290 × 7020/25
M05.1205MasonryShower, short, Hansgrohe iBox 2.0 0150, concealed body incl. overhead and hand shower connections, pipes exit at the bottom, long pipes300 × 1380 × 7020/25
M05.1220MasonryShower, short, Hansgrohe iBox 0180, concealed body incl. overhead and hand shower connections, pipes exit at the bottom, long pipes300 × 1380 × 7020/25
M05.1230MasonryShower, short, Grohe Smartbox 35604, concealed body incl. overhead and hand shower connections, pipes exit at the bottom, long pipes300 × 1380 × 7020/25
M05.1240MasonryShower, short, Hansa Blue Box 8000, concealed body incl. overhead and hand shower connections, pipes exit at the bottom, long pipes300 × 1380 × 7020/25
M05.1250MasonryShower, short, Kludi Flexx Boxx 88011, concealed body incl. overhead and hand shower connections, pipes exit at the bottom, long pipes300 × 1380 × 7020/25
M05.1206MasonryShower, short, Hansgrohe iBox 2.0 0150, concealed body incl. overhead and hand shower connections, right, pipes exit at the bottom, long pipes400 × 1380 × 7020/25
M05.1221MasonryShower, short, Hansgrohe iBox 0180, concealed body incl. overhead and hand shower connections, right, pipes exit at the bottom, long pipes400 × 1380 × 7020/25
M05.1231MasonryShower, short, Grohe Smartbox 35604, concealed body incl. overhead and hand shower connections, right, pipes exit at the bottom, long pipes400 × 1380 × 7020/25
M05.1241MasonryShower, short, Hansa Blue Box 8000, concealed body incl. overhead and hand shower connections, right, pipes exit at the bottom, long pipes400 × 1380 × 7020/25
M05.1251MasonryShower, short, Kludi Flexx Boxx 88011, concealed body incl. overhead and hand shower connections, right, pipes exit at the bottom, long pipes400 × 1380 × 7020/25
M05.1207MasonryShower, short, Hansgrohe iBox 2.0 0150, concealed body incl. overhead and hand shower connections, left, pipes exit at the bottom, long pipes400 × 1380 × 7020/25
M05.1222MasonryShower, short, Hansgrohe iBox 0180, concealed body incl. overhead and hand shower connections, left, pipes exit at the bottom, long pipes400 × 1380 × 7020/25
M05.1232MasonryShower, short, Grohe Smartbox 35604, concealed body incl. overhead and hand shower connections, left, pipes exit at the bottom, long pipes400 × 1380 × 7020/25
M05.1242MasonryShower, short, Hansa Blue Box 8000, concealed body incl. overhead and hand shower connections, left, pipes exit at the bottom, long pipes400 × 1380 × 7020/25
M05.1252MasonryShower, short, Kludi Flexx Boxx 88011, concealed body incl. overhead and hand shower connections, left, pipes exit at the bottom, long pipes400 × 1380 × 7020/25
M05.1245MasonryShower, short, Hansgrohe iBox 2.0 0150, concealed body with overhead shower connection, pipes exit at the bottom, long pipes300 × 1250 × 7020/25
M05.1260MasonryShower, short, Hansgrohe iBox 0180, concealed body with overhead shower connection, pipes exit at the bottom, long pipes300 × 1250 × 7020/25
M05.1270MasonryShower, short, Grohe Smartbox 35604, concealed body with overhead shower connection, pipes exit at the bottom, long pipes300 × 1250 × 7020/25
M05.1280MasonryShower, short, Hansa Blue Box 8000, concealed body with overhead shower connection, pipes exit at the bottom, long pipes300 × 1250 × 7020/25
M05.1290MasonryShower, short, Kludi Flexx Boxx 88011, concealed body with overhead shower connection, pipes exit at the bottom, long pipes300 × 1250 × 7020/25
M05.0491MasonryShower, long, Hansgrohe iBox 2.0 0150, for Hansgrohe Shower Select, pipes exit at the bottom, long pipes300 × 2340 × 7020/25
M05.0490MasonryShower, long, Hansgrohe iBox 0180, for Hansgrohe Shower Select, pipes exit at the bottom, long pipes300 × 2340 × 7020/25
M05.1300MasonrySingle outlet for overhead shower, short, pipes exit at the bottom, short pipes140 × 290 × 7016/20 · 20/25
T05.2250DrywallShower, short, pipes exit at the bottom, long pipes350 × 200 × 7016/20 · 20/25
T05.2255DrywallShower, short, pipes exit at the top/bottom, short pipes350 × 200 × 7016/20 · 20/25
T05.2262DrywallShower, short, Hansgrohe iBox 2.0 0150, concealed body incl. hand shower connection, pipes exit at the bottom, long pipes350 × 400 × 7016/20 · 20/25
T05.2260DrywallShower, short, Hansgrohe iBox 0180, concealed body incl. hand shower connection, pipes exit at the bottom, long pipes350 × 400 × 7016/20 · 20/25
T05.2265DrywallShower, short, Grohe Smartbox 35604, concealed body incl. hand shower connection, pipes exit at the bottom, long pipes350 × 400 × 7016/20 · 20/25
T05.2270DrywallShower, short, Hansa Blue Box 8000, concealed body incl. hand shower connection, pipes exit at the bottom, long pipes350 × 400 × 7016/20 · 20/25
T05.2275DrywallShower, short, Kludi Flexx Boxx 88011, concealed body incl. hand shower connection, pipes exit at the bottom, long pipes350 × 400 × 7016/20 · 20/25
T05.2607DrywallShower, short, Hansgrohe iBox 2.0 0150, concealed body incl. hand shower connection, right, pipes exit at the bottom, long pipes450 × 400 × 7016/20 · 20/25
T05.2605DrywallShower, short, Hansgrohe iBox 0180, concealed body incl. hand shower connection, right, pipes exit at the bottom, long pipes450 × 400 × 7016/20 · 20/25
T05.2610DrywallShower, short, Grohe Smartbox 35604, concealed body incl. hand shower connection, right, pipes exit at the bottom, long pipes450 × 400 × 7016/20 · 20/25
T05.2615DrywallShower, short, Hansa Blue Box 8000, concealed body incl. hand shower connection, right, pipes exit at the bottom, long pipes450 × 400 × 7016/20 · 20/25
T05.2620DrywallShower, short, Kludi Flexx Boxx 88011, concealed body incl. hand shower connection, right, pipes exit at the bottom, long pipes450 × 400 × 7016/20 · 20/25
T05.2627DrywallShower, short, Hansgrohe iBox 2.0 0150, concealed body incl. hand shower connection, left, pipes exit at the bottom, long pipes450 × 400 × 7016/20 · 20/25
T05.2625DrywallShower, short, Hansgrohe iBox 0180, concealed body incl. hand shower connection, left, pipes exit at the bottom, long pipes450 × 400 × 7016/20 · 20/25
T05.2630DrywallShower, short, Grohe Smartbox 35604, concealed body incl. hand shower connection, left, pipes exit at the bottom, long pipes450 × 400 × 7016/20 · 20/25
T05.2635DrywallShower, short, Hansa Blue Box 8000, concealed body incl. hand shower connection, left, pipes exit at the bottom, long pipes450 × 400 × 7016/20 · 20/25
T05.2640DrywallShower, short, Kludi Flexx Boxx 88011, concealed body incl. hand shower connection, left, pipes exit at the bottom, long pipes450 × 400 × 7016/20 · 20/25
T05.2282DrywallShower, short, Hansgrohe iBox 2.0 0150, concealed body incl. overhead shower pipe and hand shower connection, pipes exit at the bottom, long pipes350 × 400 × 7020/25
T05.2280DrywallShower, short, Hansgrohe iBox 0180, concealed body incl. overhead shower pipe and hand shower connection, pipes exit at the bottom, long pipes350 × 400 × 7020/25
T05.2285DrywallShower, short, Grohe Smartbox 35604, concealed body incl. overhead shower pipe and hand shower connection, pipes exit at the bottom, long pipes350 × 400 × 7020/25
T05.2290DrywallShower, short, Hansa Blue Box 8000, concealed body incl. overhead shower pipe and hand shower connection, pipes exit at the bottom, long pipes350 × 400 × 7020/25
T05.2295DrywallShower, short, Kludi Flexx Boxx 88011, concealed body incl. overhead shower pipe and hand shower connection, pipes exit at the bottom, long pipes350 × 400 × 7020/25
T05.2647DrywallShower, short, Hansgrohe iBox 2.0 0150, concealed body incl. overhead shower pipe and hand shower connection, right, pipes exit at the bottom, long pipes450 × 400 × 7020/25
T05.2645DrywallShower, short, Hansgrohe iBox 0180, concealed body incl. overhead shower pipe and hand shower connection, right, pipes exit at the bottom, long pipes450 × 400 × 7020/25
T05.2650DrywallShower, short, Grohe Smartbox 35604, concealed body incl. overhead shower pipe and hand shower connection, right, pipes exit at the bottom, long pipes450 × 400 × 7020/25
T05.2655DrywallShower, short, Hansa Blue Box 8000, concealed body incl. overhead shower pipe and hand shower connection, right, pipes exit at the bottom, long pipes450 × 400 × 7020/25
T05.2660DrywallShower, short, Kludi Flexx Boxx 88011, concealed body incl. overhead shower pipe and hand shower connection, right, pipes exit at the bottom, long pipes450 × 400 × 7020/25
T05.2667DrywallShower, short, Hansgrohe iBox 2.0 0150, concealed body incl. overhead shower pipe and hand shower connection, left, pipes exit at the bottom, long pipes450 × 400 × 7020/25
T05.2665DrywallShower, short, Hansgrohe iBox 0180, concealed body incl. overhead shower pipe and hand shower connection, left, pipes exit at the bottom, long pipes450 × 400 × 7020/25
T05.2670DrywallShower, short, Grohe Smartbox 35604, concealed body incl. overhead shower pipe and hand shower connection, left, pipes exit at the bottom, long pipes450 × 400 × 7020/25
T05.2675DrywallShower, short, Hansa Blue Box 8000, concealed body incl. overhead shower pipe and hand shower connection, left, pipes exit at the bottom, long pipes450 × 400 × 7020/25
T05.2680DrywallShower, short, Kludi Flexx Boxx 88011, concealed body incl. overhead shower pipe and hand shower connection, left, pipes exit at the bottom, long pipes450 × 400 × 7020/25
T05.2302DrywallShower, long, Hansgrohe iBox 2.0 0150, concealed body incl. overhead and hand shower connections, pipes exit at the bottom, long pipes350 × 1380 × 7020/25
T05.2300DrywallShower, long, Hansgrohe iBox 0180, concealed body incl. overhead and hand shower connections, pipes exit at the bottom, long pipes350 × 1380 × 7020/25
T05.2305DrywallShower, long, Grohe Smartbox 35604, concealed body incl. overhead and hand shower connections, pipes exit at the bottom, long pipes350 × 1380 × 7020/25
T05.2310DrywallShower, long, Hansa Blue Box 8000, concealed body incl. overhead and hand shower connections, pipes exit at the bottom, long pipes350 × 1380 × 7020/25
T05.2315DrywallShower, long, Kludi Flexx Boxx 88011, concealed body incl. overhead and hand shower connections, pipes exit at the bottom, long pipes350 × 1380 × 7020/25
T05.2322DrywallShower, long, Hansgrohe iBox 2.0 0150, concealed body incl. overhead shower connection, pipes exit at the bottom, long pipes350 × 1380 × 7020/25
T05.2320DrywallShower, long, Hansgrohe iBox 0180, concealed body incl. overhead shower connection, pipes exit at the bottom, long pipes350 × 1380 × 7020/25
T05.2325DrywallShower, long, Grohe Smartbox 35604, concealed body incl. overhead shower connection, pipes exit at the bottom, long pipes350 × 1380 × 7020/25
T05.2330DrywallShower, long, Hansa Blue Box 8000, concealed body incl. overhead shower connection, pipes exit at the bottom, long pipes350 × 1380 × 7020/25
T05.2335DrywallShower, long, Kludi Flexx Boxx 88011, concealed body incl. overhead shower connection, pipes exit at the bottom, long pipes350 × 1380 × 7020/25
T05.2687DrywallShower, long, Hansgrohe iBox 2.0 0150, concealed body incl. overhead shower connection, right, pipes exit at the bottom, long pipes450 × 1380 × 7020/25
T05.2685DrywallShower, long, Hansgrohe iBox 0180, concealed body incl. overhead shower connection, right, pipes exit at the bottom, long pipes450 × 1380 × 7020/25
T05.2690DrywallShower, long, Grohe Smartbox 35604, concealed body incl. overhead shower connection, right, pipes exit at the bottom, long pipes450 × 1380 × 7020/25
T05.2695DrywallShower, long, Hansa Blue Box 8000, concealed body incl. overhead shower connection, right, pipes exit at the bottom, long pipes450 × 1380 × 7020/25
T05.2700DrywallShower, long, Kludi Flexx Boxx 88011, concealed body incl. overhead shower connection, right, pipes exit at the bottom, long pipes450 × 1380 × 7020/25
T05.2707DrywallShower, long, Hansgrohe iBox 2.0 0150, concealed body incl. overhead shower connection, left, pipes exit at the bottom, long pipes450 × 1380 × 7020/25
T05.2705DrywallShower, long, Hansgrohe iBox 0180, concealed body incl. overhead shower connection, left, pipes exit at the bottom, long pipes450 × 1380 × 7020/25
T05.2710DrywallShower, long, Grohe Smartbox 35604, concealed body incl. overhead shower connection, left, pipes exit at the bottom, long pipes450 × 1380 × 7020/25
T05.2715DrywallShower, long, Hansa Blue Box 8000, concealed body incl. overhead shower connection, left, pipes exit at the bottom, long pipes450 × 1380 × 7020/25
T05.2720DrywallShower, long, Kludi Flexx Boxx 88011, concealed body incl. overhead shower connection, left, pipes exit at the bottom, long pipes450 × 1380 × 7020/25
T05.2341DrywallShower, long, Hansgrohe iBox 2.0 0150, for Hansgrohe Shower Select, pipes exit at the bottom, long pipes350 × 1390 × 7020/25
T05.2340DrywallShower, long, Hansgrohe iBox 0180, for Hansgrohe Shower Select, pipes exit at the bottom, long pipes350 × 1390 × 7020/25
T05.2345DrywallSingle outlet, overhead shower outlet350 × 290 × 7016/20 · 20/25

With a built-in concealed valve body

Most shower boxes come with the concealed valve body of a fitting manufacturer, in place and piped: Hansgrohe iBox 2.0 0150, Hansgrohe iBox 0180, Grohe Smartbox 35604, Hansa Blue Box 8000 or Kludi Flexx Boxx 88011. You choose the trim to match this concealed valve body.

Depending on the box, a connection for the hand shower is included, arranged on the right or left as well, plus a connection pipe or a connection for the overhead shower; some boxes lead only to the overhead shower. For Hansgrohe ShowerSelect there are dedicated boxes with an iBox.

Without a concealed valve body

For a surface-mounted fitting the shower box is available with two wall-plate elbows: 240 × 200 mm in masonry, long 240 × 1250 mm, and 350 × 200 mm in drywall. The pipes run down, and with the bottom/top pipe routing optionally up as well.

Shower box with or without a concealed valve body?

With concealed valve bodyWithout concealed valve body
FittingTrim to match the built-in concealed valve bodySurface-mounted fitting
ConnectionPipes run right into the concealed valve bodyTwo wall-plate elbows
ShowersHand shower, overhead shower or both, depending on the boxVia the fitting
Dimensions in masonry300 to 450 mm wide, 400 to 2340 mm high240 × 200 mm, long 240 × 1250 mm

Pipe systems for the shower connection
